A3 Handheld FTTx Fusion Splicer

4.3" HD color LCD touch screen
New design GUI for convient using
Applicable to various optical fibers
Vgroove accurate alignment and low loss
Availability:
Quantity:
  • A3

  • SHINHO

Product Description


Specially Designed For FTTx/FTTH Projects


◆ 7s splicing & 20s heating

◆ Real-time discharge calibration

◆ Intelligent menu design

◆ Large fiber magnification

◆ Compact size, light weight, handheld fusion splicer

◆ More stable performance,anti-shock, water-resistant

◆ Supports touch with GUl for smooth operation

◆ The fixture is suitable for bare fiber, patch cord, pigtail, FTTH fiber

◆ Suitable for FTTH project, security monitoring etc.



MORE INFO



>4000 times discharging

Automatic ARC calibration

Inductive automatic heater

No heating without fiber

Long time working battery

250 cycles splice & heat



SPECIFICATIONS


Applicable Fiber

G651/G652/G653/G655/G657 etc.

Cladding Diameter

80~150μm

Coating Diameter

160~3000μm

Cleaved Length

5~16mm (coating diameter<250μm), 16mm (coating diameter:250~1000μm)

Typical Splice Loss

G651: 0.01dB; G652: 0.02dB; G653: 0.04dB; G655: 0.04dB; G657: 0.02dB

Return Loss

>60dB

Splicing Program

40 modes

Operation Mode

Manual/Auto

Auto-Heating

Available

Splicing Time

7~12 seconds

Heating Time

20~26 seconds for 40mm and 60mm shrinkable sleeves

Fiber Magnification

320X (X or Y view), 160X (X and Y view)

Viewing display

Dual high sensitivity camera, 4.3" HD color LCD touch screen

Data Storage

8000 groups fusion records

Loss Evaluation

Available

Tension Test

1.8~2.2N

Interface

GUI menu interface, easy for operation

Battery Capacity

Detachable 5200mAh Li-battery, typical 250 cycles splicing and heating

Power Supply

Adapter, input: AC100~240V (50/60Hz), output: DC11~13.5V

Electrode Life

More than 4000 ARC discharges, easy to replace

Terminal

USB 2.0 port, for software upgrading, records exporting

Operating Condition

Altitude: 0~5000m; Humidity: 0~95%; Temperature: -10°C~+50°C; Max wind: 15m/s

Dimension/Weight

160mm(L) × 140mm(W) × 135mm(H)(including rubber bumper)/1.97kg (with battery)


PACKAGE


Fusion Splicer

Fiber Cleaver

Drop Cable Stripper

Fiber Stripper

Power Plug

Power Adapter

Strap

Spare Electrodes

User Manual

Cooling Tray

Cleaning Brush

Carrying Case
